Features:
1. Full shielded with a rugged cast-encased rear, utilizing an innovtative tool free termination.
2. Easy reliable and stable quality by insert-molding and press-fit assembly process.
3. Fits for 1U 24 port and 1U 48 port keystone panel.
4. Suitable for cabling from the smallest home networks to very large data centers.
5. Cable entrance diameter range: 5.5mm-9.0mm.
6. Insulation diameter range: 0.95mm-1.62mm.
7. Solid and Stranded conductor: 22-26AWG.
Material:
Jacking Housing: Zinc die-casting with Nickel plated
Spring Pin: Phosphor Bronze,Nickel undercoat,Gold plating 50u”
Pin Holder: PBT
PCB: FR-4
